Touch screen acidity meter P10 series instrument features:
7-inch color high-resolution (1024 * 600) capacitive touch screen, high sensitivity, complete parameter display, intuitive, easy to use, and simple to use.
Compliant with international GLP requirements, it has intelligent functions such as automatic calibration, automatic temperature compensation, data storage, USB output, clock display, wireless printing, function settings, and self diagnostic information.
The instrument is equipped with a bilingual operating system in both Chinese and English, with a user-friendly design and adjustable brightness
The built-in large capacity storage can store 2000 sets of measurement data, which can be transferred through USB storage. The stored data can be opened with the general office software EXELL for easy editing by customers.
Automatically identify pH standard buffer solutions, with three series of standard buffer solutions to choose from: European and American series, NIST series, and Chinese series.
Intelligent judgment of electrode status to ensure accurate application for customers.
The instrument is equipped with a Bluetooth module that supports wireless Bluetooth printing, making it convenient for users to operate. Optional support for wireless Bluetooth transmission of data to mobile phones and computers.
Designed to meet the IP54 dust and splash protection rating.
Touch screen acidity meter P10 instrument parameters:
Model: P10
Display screen: 7-inch color high-resolution (1024 * 600) capacitive touch screen
PH measurement range: -2.00 to 19.99 pH
PH resolution: 0.01pH
Relative accuracy of pH: ± 0.02pH
Input current: ≤ 2 × 10-12 A
Input impedance: ≥ 1 × 1012 Ω
MV measurement range:- 1999~1999mv
MV resolution: 1mV
MV relative accuracy: ±0.1%FS
Temperature measurement range: 0-100 ℃
Temperature resolution: 0.1 ℃
Temperature compensation Temp Compensation： Manual/Automatic (0-100) ℃
Automatic Calibration: 1-3 point calibration
GLP standard: Compliant with
Buffer solutions: European and American series, NIST series, and Chinese series
Data storage: 2000 sets
Communication interface: USB 2.0, Bluetooth wireless (optional)
Working conditions: Temperature: 5-40 degrees, Humidity: 5-85%
Power supply: 12V1A (110-220, 50Hz-60Hz adapter)
Product size and weight: 160 × 190 × 70mm/880g
Touch screen acidity meter P10 series instrument standard configuration:
1. One desktop large screen acidity meter (configured according to model)
2. Composite electrode (customers can choose other pH electrodes according to different test samples) 1 piece
3. One temperature electrode
4. One universal electrode holder
5. One set of pH correction buffer each
6. One 12V power adapter (for instrument use)
7. One copy of the instruction manual
8. Brief operation guide
|
