HG-1 | Mercury argon lamp calibration light source

The mercury argon lamp produced by Shanghai Wenyi Optoelectronics Technology Co., Ltd. is a compact, low-cost HG-1 mercury argon calibration light source used for wavelength calibration in UV-VIS-NIR spectroscopy systems. HG-1 produces a spectral range of 253-1700nm in the UV visible band, used for fast and reliable wavelength correction. The shell is printed with easily recognizable mercury and argon transmission spectral lines.

Our spectrometer has been carefully calibrated. However, with the passage of time and changes in the environment, the wavelength may experience slight drift. If wavelength accuracy is important for your application, you can consider calibrating the wavelength every time. You can readjust the optical spectrometer and perform linear regression using the characteristic peaks in the following spreadsheet.

Features:

SMA905 connector (FC connector optional)

Wavelength range 253-1700nm

Calibrate the light source. Generate mercury and argon atomic emission lines for calibrating spectrometers

Easy to operate. Calibration with the spectrometer system only requires a power supply and optical fiber.

Due to differences in the curves obtained by spectrometers with different responses, the following is a comparison chart of the curves of our company's MAX2000-PRO full band scintillation spectrometer and EQ4000 single grating scintillation spectrometer, for reference only!

Calibration curve of MAX2000-PRO full band scintillation spectrometer	Calibration curve of EQ4000 single grating scintillation spectrometer

HG-PS-1 pen shaped calibration mercury lamp

In our conventional optical instruments, most products require regular calibration. The HG-PS-1 pen shaped calibration mercury lamp is a product used for calibrating spectral analysis instruments. This product has a small size and is convenient for handheld calibration of optical measuring equipment such as desktop spectrometers or spectrophotometers.

physical object image	Instructions	introduction diagram	Size chart
	The wavelength range of the pen shaped mercury lamp is 253-1700nm. The handle is made of PTFE material, quartz tube, equipped with a power adapter, and the power supply voltage is 220V. During use, it is recommended that users wear goggles; This product generates ozone and is recommended for use in a ventilated environment.
